Technical parameters |
|---|
| Length of the working table |
450 mm |
| Width of the working table |
150 mm |
| Maximum height of the grinded workpieces (for a new grinding wheel) |
250 mm |
| Power of the spindle drive |
1.8 kW |
| Maximum rotary speed of the spindle |
2680 1/min |
| Minimum longitudinal feed rate (Z-axis) |
3 m/min |
| Maximum longitudinal feed rate (Z-axis) |
25 m/min |
| Diameter of a new grinding wheel |
200 mm |
| Maximum diameter of a grinding wheel |
76 mm |
| Diameter hole in the grinding wheel |
32 mm |
| Maximum length of grinding (without the grinding wheel output) X-axis |
400 mm |
| Maximum width of grinding (without the grinding wheel output) Y-axis |
130 mm |
| Machine height |
1600 mm |
| Machine length |
1500 mm |
| Machine width |
1300 mm |
| Machine weight |
1.6 t |
