Technical parameters |
|---|
| Clamping force |
76.5 t |
| Injection weight |
120 g |
| Minimum distance between the plates for mounting the mold |
250 mm |
| Maximum distance between the plates for mounting the mold |
625 mm |
| Length of the injection mold stroke |
375 mm |
| Height of the plate for mounting the mold |
490 mm |
| Width of the plate for mounting the mold |
490 mm |
| Distance between the columns (horizontal) |
320 mm |
| Distance between the columns (vertical) |
320 mm |
| Power of the ejector |
38 t |
| Length of the ejector stroke |
150 mm |
| Screw diameter |
35 mm |
| Length of the screw stroke |
150 mm |
| Maximum injection pressure |
150 MPa |
| Pump power |
15 kW |
| Oil tank capacity |
220 l |
| Total power demand |
20.4 kW |
| Length of the stroke of the injection nozzle |
240 mm |
| Pressure force of the injection nozzle |
6.1 t |
| Machine length |
4300 mm |
| Machine width |
1850 mm |
| Machine height |
2000 mm |
| Weight of the injection molding machine |
3.1 t |
