CNC Vertical Machining Center DMG DMC 635 V ECO

Category CNC Milling Machines and Machining Centers DMG ›
Manufacturer DMG ›

ARCHIVED AD
CNC Vertical Machining Center DMG DMC 635 V ECO was manufactured by the machine manufacturer DMG. Machine DMG DMC 635 V ECO was built in 2008 year.

General data

Location Poland
region Dolnośląskie
Year of manufacture 2008
Warranty Without warranty
Technical condition Good
Payment Before receipt
Transport The buyer organizes the transport at his own cost
Status A test can be performed

Technical parameters

Maximum table load (evenly distributed) 600 kg
Number of tools in the magazine 20 pcs
Minimum rotary speed of the vertical spindle 20 1/min
Maximum rotary speed of the vertical spindle 8000 1/min
Minimum distance of the spindle from the table 120 mm
Maximum distance of the spindle from the table 580 mm
Travel length X-axis (mechanical feed) 635 mm
Travel length Y-axis (mechanical feed) 510 mm
Travel length Z-axis (mechanical feed) 460 mm
Maximum feed rate in X-axis 333.3 mm/s
Maximum feed rate in Y-axis 333.3 mm/s
Maximum feed rate in Z-axis 333.3 mm/s
Total power demand 17 kW
Machine height 2650 mm
Machine length 2050 mm
Machine width 2530 mm
Machine weight 3.7 t

Equipment

SINUMERIK 810D
Central lubrication
Technical documentation
