Technical parameters |
|---|
| Length of the working table |
1600 mm |
| Width of the working table |
510 mm |
| Power of the spindle drive |
7.5 kW |
| Minimum rotary speed of the vertical spindle |
40 1/min |
| Maximum rotary speed of the vertical spindle |
3000 1/min |
| Maximum distance of the spindle from the table |
550 mm |
| Travel length X-axis (mechanical feed) |
1200 mm |
| Travel length Y-axis (mechanical feed) |
510 mm |
| Travel length Z-axis (mechanical feed) |
550 mm |
| Maximum feed rate in X-axis |
41.7 mm/s |
| Maximum feed rate in Y-axis |
41.7 mm/s |
| Maximum feed rate in Z-axis |
41.7 mm/s |
| Machine height |
2915 mm |
| Machine length |
2415 mm |
| Machine width |
2400 mm |
| Machine weight |
5 t |
